►The ATC13 transfer case is found in BMW’s latest X5, X6, and X7 models. It does a fine job when functioning, but that’s not guaranteed, as they’ve become a regular failure point. Replacing the transfer case when it fails is the only fix, so this is one job you may have to do. It can be done at home with the right tools and plenty of patience, as long as you follow our replacement guide.

The transfer case splits the engine torque, sending some of it forward to the front axle. It uses a clutch pack, a chain, and a few other moving pieces to make that happen, and they require a lubricating oil for safe operation. BMW’s lifetime fluid claim has led many of these transfer cases to fail due to worn fluid, so consider a fluid service if your transfer case has yet to experience any failure symptoms. Those symptoms include binding and hesitation under acceleration, and a handful of related fault codes.

In this video, Cole Evans, FCP Euro’s In-House Technician, removes and reinstalls the transfer case on a BMW G05 X5.

Shop the parts used in this video: https://www.fcpeuro.com/products/bmw-transfer-case-installation-kit-27107889034kt2?utm_source=youtube&utm_medium=description&utm_campaign=mps%20bmw%20g05%20×5&utm_content=transfer%20case%20

This video applies to the following vehicles:
BMW X5
2019 BMW X5 xDrive50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44M0 Gas
2020 BMW X5 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2020 BMW X5 xDrive50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44M0 Gas
2021 BMW X5 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2022 BMW X5 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2023 BMW X5 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
Notes: Up to 08/2022

BMW X7
2019 BMW X7 xDrive50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44M0 Gas
2020 BMW X7 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2020 BMW X7 xDrive50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44M0 Gas
2021 BMW X7 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2022 BMW X7 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas

BMW X6
2020 BMW X6 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2021 BMW X6 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2022 BMW X6 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
2023 BMW X6 M50i Transfer Case
Automatic AWD Sport Utility 4.4L V8 N63B44T3 Gas
Notes: Up to 08/2022

00:00 – Intro
02:42 – Tools Needed
04:50 – Putting the Transfer Case in Oil Service Mode
06:36 – Underbelly Pan & Exhaust Removal
09:49 – Heat Shield Removal
12:13 – Transfer Case Bracket Removal
13:33 – Transfer Case Fluid Drain
14:37 – Drive Shaft Removal
18:01 – Transfer Case Removal
20:29 – Setting up the New Transfer Case
25:30 – Transfer Case Installation
29:21 – Drive Shaft Installation
33:20 – Transfer Case Fluid Fill
34:22 – Transfer Case Bracket Installation
37:04 – Heat Shield Install
39:21 – Exhaust Installation
44:50 – Underbelly Pan Installation
45:47 – Wrap Up
