How to Build a Suzuki Quadzilla LT500R Engine | 1987 – 1990 Full Build Step by Step
#2stroke #lt500r #quadzilla
CHAPTERS
0:00 – Intro
CENTER CASES
1:02 – Crank Installation
3:34 – Transmission Installation
4:32 – Shift Drum/Forks/Detent
8:02 – Center Case Assembly
10:40 – Shift Cam Bolt
11:23 – Sprocket/Countershaft
STATOR SIDE
12:02 – Counter Balancer
12:30 – Stator/Flywheel Assembly
CLUTCH SIDE
15:12 – Gearshift Cam/Shift Shaft
17:29 – Kick Start Assembly
18:41 – Power Valve Actuator
19:17 – Primary Drive Spacer/Gear
19:54 – Counter Balancer/Drive Gear
21:33 – Power Valve Governor
22:20 – Primary Drive and Counter Balancer Tightening
23:25 – Kicker Idler Gear
23:52 – Clutch Assembly
27:49 – Clutch Cover Installation
TOP END
29:27 – Piston Installation
31:22 – Power Valve Installation
33:53 – Cylinder Installation
36:44 – Head/Dome Installation
38:13 – Reeds/Intake Boot Installation
39:00 – Exhaust Flange Installation
39:31 – Power Valve Cover Installation
39:41 – Water Pump Impeller/Cover
SHOWCASE/CLOSING
40:45 – Showcasing/Running The Engine
42:18 – Closing
